10.15.5 Terra 60
Parameter Specification [A]
Maximum rated input current 93
Maximum rated input current with AC
socket
125
10.16 DC output specifications
10.16.1 General specifications
Parameter Specification
DC output voltage range, CCS 200-920 V DC
DC output voltage range, CHAdeMO 150-500 V DC
(In Japan 150-450 V DC)
Minimum DC output current 15 A
Connection standard CHAdeMO 1.2
CCS (IEC 61851-23:2014 , IEC62196-1:
2014, IEC 62196-3: 2014)
10.16.2 Terra 360
Parameter Specification
DC output power, mode 1, continuously
on one EV charge cable
Maximum 360 kW
DC output power, mode 2, continuously
on two EV charge cables
Maximum 90 kW
Simultaneous DC on two outlets Yes. Two DC outputs operate in parallel.
Maximum DC output current CCS 500 A
Maximum DC output current CCS Cooled
cable (option)
500 A
Maximum DC output current CHAdeMO Options: 150 A or 200 A, depending on
cable type
Note:
• The user can select mode 1 or 2.
• You can install a cooled cable on a standard EVSE.
Technical data
9AKK108467A6398-EN | 002 119
