ABB Terra 360 CE User Manual

5.7.5 Connect the PE wire (Terra 360)
Preliminar
y requirements
• The front and right doors
are open.
• Cable lug M11
• F
asteners M11
•
Installation engineer
•
• Make sure that the earthing
connec
tion is in accordance
with the standard IEC
60364-5-54.
• Wire stripper pliers
• Wir
e cutter
• Crimp plier tool
• Torque socket wrench
Procedure
1. Pr
epare the PE wire.
a. Cut the PE wire (A) to the length that is sufficient for connection to the PE
busbar (B).
b. Install the cable lug (C) to the end of the wire. Use the crimp plier tool.
2. Attach the PE wire to the PE busbar. Use the fasteners (D).
Note: The Terra 360 model has an addit
ional PE busbar to connect the
cable in vertical position (big size cable).
3. Tighten the fasteners to the correct torque. For the specification, refer to
sect
ion 10.7.
1
2
2
C
B
D C B
A
Installation
9AKK108467A6398-EN | 002 71
