Working point Electric load VTHD (L1/L2/L3) ITHD (L1/L2/L3)
400 V - 300 A 100 % 2.26 % - 2.33 % -
2.50 %
3.73 % - 3.56 % -
4.00 %
Order Phase L1 Phase L2 Phase L3
I rms I rms I rms
[A] [A] [A]
39 0.21 0.21 0.07
40 0.09 0.08 0.05
41 0.22 0.20 0.22
42 0.08 0.02 0.06
43 0.19 0.20 0.16
44 0.05 0.05 0.06
45 0.15 0.15 0.05
46 0.06 0.07 0.06
47 0.36 0.28 0.21
48 0.07 0.03 0.05
49 0.22 0.21 0.26
50 0.05 0.05 0.05
10.14.2 Terra 180, equal share
Working point Electric load VTHD (L1/L2/L3) ITHD (L1/L2/L3)
400 V - 200 A 100 % 0.47 % - 0.46 % -
0.48 %
4.29 % - 3.92 % -
4.23 %
Order Phase L1 Phase L2 Phase L3
I rms I rms I rms
[A] [A] [A]
1
122.86 123.63 122.92
2 0.30 0.36 0.49
3 0.66 0.21 0.48
4 0.26 0.36 0.39
5 4.28 3.59 4.18
6 0.56 0.26 0.32
7 1.62 2.01 1.71
8 0.24 0.29 0.16
9 0.20 0.43 0.05
10 0.37 0.30 0.43
11 1.56 1.69 1.62
12 0.66 0.41 0.28
13 0.94 1.00 1.06
14 0.29 0.33 0.19
Technical data
114 9AKK108467A6398-EN | 002
