ABB Terra 360 CE User Manual

Parameter Function or specification
MV switch Dedicated MV/LV transformer for indus-
trial use of the EVSE
For residential use of the EVSE you can
connect directly to low voltage public
grid
Automatic circuit breaker Output 4 x 400 A, 690 Vac
Additional option: Residual current
breaker type B
Caution: A
residual
current
breaker
type B is
Mandatory
for an EVSE
with CHA-
deMO out-
put.
Output 4 x 400 A, gG Fuses, 690 Vac
Adjustable Idn 30 to 300 mA
10.21 In-rush current
Current peaks during the start of a charge session
Parameter
Specification [µs]
Duration of the current peaks 25
Maximum current peak (400 VAC and 50/60 Hz)
Parameter
Specification [A]
Terra 360 < 458 duration 1.68 ms
Terra 180 < 458 duration 1.68 ms
Terra 60 < 152 duration 1.5 ms
Maximum current peak (480 VAC)
Parameter
Specification [A]
Terra 360 < 550 duration 1.68 ms
Terra 180 < 550 duration 1.68 ms
Terra 60 < 183 duration 1.5 ms
10.22 Cleaning specifications
Parameter Specification
Cleaning agent pH value between 6 and 8
Non-abrasive tool Non-woven nylon hand pad
Technical data
128 9AKK108467A6398-EN | 002
