ABB Terra 360 CE User Manual

Parameter Specification
Torque socket wrench 5 to 20 Nm, size M8 (13 mm) and M6 (10
mm)
Ratchet spanner with socket and exten-
sion
Size: M5 (8 mm) and M6 (10 mm)
Tie-wraps Standard
Voltage tester To switch 200 mA of test current (exam-
ple: Duspol)
Digital multimeter Standard
Hoisting equipment or forklift truck Capable to lift the EVSE safely. Take into
account the dimensions, the mass, the
center of gravity and the maximum tilt
angle. Refer to different sections in this
document.
Swivel eye bolts or bolts with lifting
loops (to use with hoisting equipment)
Thread M10
Wire stripper pliers and wire cutter To strip the wires of the AC input cable
Crimp plier Size: M11
10.6 Required parts for installation
Parameter Specification
Swivel eye bolts or bolts with lifting
loops, to use with the hoisting equip-
ment
Thread M10
Cable lugs and fasteners Size: M10 (AC wires)
Size: M11 (PE wire)
10.7 Torque specifications
Parameter Specification
[Nm] [lb-in]
Fasteners for the PE wire Between 4 and 6 Between 35 and 53
Fasteners for the L1, L2, L3 and neutral
wire (Terra 360)
Between 30 and 44 Between 265 and
390
Fasteners for the L1, L2, L3 and neutral
wire (Terra 180)
28 247
Fasteners for the L1, L2, L3 and neutral
wire (Terra 60)
Between 50 and 75 Between 443 and
664
Fasteners for the connection of the cabi-
net to the base (M12 bolt)
10 88.5
Technical data
98 9AKK108467A6398-EN | 002
