ABB Terra 360 CE - EVSE Derating During Heavy Duty Operation; Harmonics; Harmonics Terra 360, Equal Share

Parameter Specification
Model Installed power Rated power [kW]
Terra 360 6 power modules
(180)
150
Terra 360 8 power modules
(240)
200
Terra 360 12 power modules
(360)
300
10.13.4 EVSE derating during heavy duty operation
Normal duty operation applies for use in public applications with moderate traffic.
Parameter
Specification Example of
power out-
put for Ter-
ra 360-12PM
Ambient temperature Power Out-
put (see
heavy duty
rating)
De-rating
[°C] [°F] [%] [%]
[kW]
- 35 … + 20 - 31 … + 68 100 - 300
+ 21 … + 25 + 69 …+ 77 100 - 300
+ 26 … + 30 + 68 …+ 86 100 - 300
+ 31 … + 35 + 87 …+ 96 100 - 300
+ 36 … + 40 + 96 …+ 104 100 - 300
+ 41 … + 45 + 105 …+ 113 98 2 294
+ 46 … + 50 + 114 …+ 122 97 3 291
+ 51 … + 55 + 123 …+ 131 95 5 285
The output power of the EVSE can be limited by the temperature of the charge
connector. This limitation can be caused by the connector model and rating, the EV
socket rating and the ambient conditions.
10.14 Harmonics
10.14.1 Harmonics Terra 360, equal share
Working point Electric load VTHD (L1/L2/L3) ITHD (L1/L2/L3)
400 V - 300 A 100 % 2.26 % - 2.33 % -
2.50 %
3.73 % - 3.56 % -
4.00 %
Order Phase L1 Phase L2 Phase L3
I rms I rms I rms
[A] [A] [A]
1
181.08 181.49 182.42
2 0.41 0.13 0.47
3 1.43 0.22 1.23
Technical data
112 9AKK108467A6398-EN | 002
