10.8 Ambient conditions
Parameter Specification
Environment, general Indoor and outdoor
Storage temperature -40 °C to +70 °C
Temperature during use -35 °C to +55 °C
Maximum altitude above sea level 2500 m
Temperature derating 40 °C
10.9 Tilt sensor specifications
10.9.1 General specifications
Parameter Specification
Voltage input 20..24 V DC
Power consumption Maximum 30 mA
Reverse polarity protection Yes
Isolation Rating 300 V
10.9.2 Wire specifications
Tilt sensor cables Specifications
Number of cores One twisted pair (total of two cores)
Diameter of cores 18 AWG
Diameter outside 5 to 10 mm (0.20 to 0.39 in)
Conductor Fine strand copper wire
Insulation PVC or other material that is serviceable
for outdoor use and UV-protected
Minimum test 1.5 kV
Strip length 11 mm (0.43 in)
Voltage rating 600 V
Shielded wire Not required
Technical data
9AKK108467A6398-EN | 002 99
