Page #77 background imageLoading...
Page #77 background image
5.8.4 Connect the tilt sensors
Preliminary requirements
Installation engineer Torque screw driver
Wire cutter
Wire stripper pliers
Crimp pliers
For the specifications of the wires and the strip length, refer to section 10.9.2.
For the wiring diagram, refer to section 10.9.3.
Procedure
1. Prepare the wires.
2. Loosen the screws of the terminal block.
3. Connect these wires. :
1. V+ wire from the external customer interface, to the terminal V+.
2. Ground wire from the external customer interface, to the terminal GND.
3. First contact wire from the external customer interface, to the terminal NC.
4. Second contact wire from the external customer interface, to the terminal
COM.
4. Tighten the screws to the correct torque. For the specifications, refer to 10.7.
5.9 Prepare for commissioning
Preliminary requirements
Installation engineer
Danger:
Hazardous voltage
Do not commission the EVSE. Only a service engineer of the
manufacturer is qualified to commission the EVSE.
Installation
9AKK108467A6398-EN | 002 77
