Make sure that the installed EVSE complies with ADA requirements. The distance
from the base of the EVSE to the minimum and maximum height of the user
operable elements must be accordance with the ADA recommendations.
Note:
It is the responsibility of the installer to make sure that the EVSE
complies with ADA requirements.
10.12 Communication interface specifications
General specifications
Parameter
Specification
RFID standard ISO 14443 A+ B to part 4 and ISO/IEC
15693
RFID-supported applications Mifare, NFC, Calypso, Ultralight, PayPass,
HID and other
Network connection 3G/4G modem, Ethernet
Ethernet cable
Parameter
Specification
Ethernet type RJ45
Cable type 8P + PE, shielded
Example of a cable for distance of 75 m
or less
HELUKAT 600E
Bandwidth, upload Minimum 128 kbit/s
Bandwidth, download Minimum 4 Mbit/s
Availability 99.9%
10.13 EVSE power rating
10.13.1 EVSE rating during normal duty operation
Normal duty operation applies for use in public applications with moderate traffic.
Parameter
Specification
Model Installed power Rated power [kW]
Terra 360 6 power modules
(180)
180
Terra 360 8 power modules
(240)
240
Terra 360 12 power modules
(360)
360
10.13.2 EVSE derating during normal duty operation
The below table represents the peak rating of the EVSE at specific ambient
temperatures.
Technical data
110 9AKK108467A6398-EN | 002
