ABB Terra 360 CE User Manual

10.16.3 Terra 180
Parameter Specification
DC output power, mode 1, continuously
on one EV charge cable
Maximum 180 kW
DC output power, mode 2, continuously
on two EV charge cables
Maximum 90 kW
Simultaneous DC on two outlets Yes. Two DC outputs operate in parallel.
Maximum DC output current CCS Nominal: 300 A
Boost: 400 A
Maximum DC output current CCS Cooled
cable (option)
500 A
Maximum DC output current CHAdeMO Options: 150 A or 200 A, depending on
cable type
Note:
• The user can select mode 1 or 2.
• You can install a cooled cable on a standard EVSE.
Output current in function of output voltage
A
100 200 300 400 500 600
B
700 800 900
300A
500A
0
100
200
300
400
600
500
A Output current [A]
B Output voltage [V]
Technical data
9AKK108467A6398-EN | 002 121
