5 Installation
5.1 General installation procedure
Preliminary requirements
• All required permits to
agree with the local rules,
are granted.
• The AC input cable is
available.
• Tools for installation. Refer
to section 10.5.
• Installation engineer • There is no voltage on
the AC input cable during
the complete installation
procedure.
Procedure
1. Prepare the site. Refer to section 5.2.
2. Prepare the foundation. Refer to section 5.3.
3. Detach the cabinet base. Refer to section 5.4.2.
4. Remove the base from the pallet.
5. Prepare the cables. Refer to section 5.5.
6. Install the EVSE. Do these steps:
a. Do the mechanical installation. Refer to section 5.6.
b. Do the electrical installation. Refer to section 5.7.
c. Install the tilt sensors. Refer to section 5.8.
7. Prepare for commissioning. Refer to section 5.9.
5.2 Site preparation
5.2.1 Prepare the site
Preliminary requirements
• Installation engineer
Procedure
1. Make sure that the space and the airflow around the cabinet is sufficient. Refer
to section 5.2.2.
2. If the local rules require the installation of an external residual-current device,
install an external residual-current device. Refer to section 3.10.
3. Design the site so that the charge cables can get to the inlet for the charge
cables on the EVs. For the length of the charge cables, refer to section 10.11.2 or
10.11.1.
Installation
9AKK108467A6398-EN | 002 57
