Dimensions and mass
WEIGHT AND DIMENSIONS
Specification Desc./Quantity
Max. length 2130 mm (83.86 in)
Max. width 810 mm (31.89 in)
Max height (at handlebar) 1110 mm (43.70 in)
Wheelbase 1465 mm (57.68 in)
Kerb weight 218 Kg (481 lb)
Weight fully loaded 435 kg (959 lb)
Engine
ENGINE
Specification Desc./Quantity
Model M55CM
Type Four-stroke longitudinal 90° V twin-cylinder with 4 valves per
cylinder, 2 cam shafts at the big end.
Cylinder number 2
Total engine capacity 896.1 cm³ (54.68 cu in)
Bore / stroke 92 x 67.4 mm (3.62 x 2.65 in)
Compression ratio 11.5: 1
Start-up Electric
Intake valve clearance 0.10 - 0.15 mm (0.0039 - 0.0059 in)
Exhaust valve clearance 0.15 - 0.20 mm (0.0059 - 0.0078 in)
Engine idle speed 1450 +/- 100 rpm
Rpm of the engine at full power 8750 +/- 100 rpm
Clutch Multi plate wet clutch with mechanical control lever on left side
of the handlebar.
Lubrication Wet crankcase. Pressure-fed, controlled by trochoidal pump
Air filter With dry filter cartridge
Cooling Liquid
GEARBOX
Specification Desc./Quantity
Type Mechanical, 6 speeds with foot lever on the left hand side of
the engine
Transmission
DRIVE RATIOS
Specification Desc./Quantity
Drive ratio Primary gear 40/69
Drive ratio, 1st gear 14/36 (secondary)
Drive ratio, 2nd gear 17/32 (secondary)
Drive ratio, 3rd gear 20/30 (secondary)
Drive ratio, 4th gear 22/28 (secondary)
Drive ratio, 5th gear 23/26 (secondary)
Drive ratio, 6th gear 24/25 (secondary)
Final drive ratio 16/44
Capacities
CAPACITY
Specification Desc./Quantity
Fuel (reserve included) 14.5 l (3.19 UK gal; 3.83 US gal)
Characteristics SHIVER 900
CHAR - 12
