APRILIA SHIVER 900 User Manual

•
Loosen and tighten again the spark plug to the specified torque.
CAUTION
TIGHTEN THE SPARK PLUG CORRECTLY. OTHERWISE, THE ENGINE MAY OVERHEAT AND
GET IRRETRIEVABLE DAMAGED.
USE ONLY THE RECOMMENDED TYPE OF SPARK PLUG, OTHERWISE, ENGINE DURATION
AND PERFORMANCE COULD BE COMPROMISED.
Engine oil
Check
Check the engine oil level frequently.
NOTE
CARRY OUT MAINTENANCE OPERATIONS AT HALF THE INTERVALS SPECIFIED IF THE VE-
HICLE IS USED IN PARTICULAR RAINY OR DUSTY CONDITIONS, OFF ROAD OR FOR TRACK
USE.
THE OIL LEVEL MUST BE CHECKED WHEN THE ENGINE IS WARM.
CAUTION
DO NOT LET THE ENGINE IDLE WITH THE VEHICLE AT A STANDSTILL TO WARM UP THE
ENGINE AND OBTAIN THE OPERATING TEMPERATURE OF ENGINE OIL.
PREFERABLY CHECK THE OIL AFTER A JOURNEY OF AFTER TRAVELLING APPROXIMATELY
15 Km (10 miles) IN EXTRA-URBAN CONDITIONS (ENOUGH TO WARM UP THE ENGINE OIL TO
OPERATING TEMPERATURE).
•
Shut off the engine.
•
Keep the vehicle upright with both
wheels on the earth.
•
Using the relative opening on the en-
gine casing, check the oil level.
MAX (top notch) = maximum level.
MIN (bottom notch) = minimum level
•
The level is correct if it reaches the
"MAX" level.
SHIVER 900 Maintenance
MAIN - 69

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
