APRILIA SHIVER 900 User Manual

Pos. Description Type Quantity Torque Notes
4 Oil filter - 1 14 Nm (10.33 lb ft) -
5 Oil pressure regulation valve M16x1.5 1 41 Nm (30.24 lb ft) -
6 Oil pump / bulkhead fastening
screws
M6x45 2 5 Nm (3.69 lb ft) 3M SCOTCH GRIP
2353
7 Strainer fastening screws - 2 12 Nm (8.85 lb ft) -
8 Oil pump gear fastener nut M6 1 11 Nm (8.11 lb ft) -
9 Gear sensor fastening screws M5x16 2 5 Nm (3.69 lb ft) 3M SCOTCH GRIP
2353
10 Oil temperature sensor M10x1 1 13 Nm (9.59 lb ft) -
Removing
•
Press the raised side of the safety
washer back into place
•
Block the pump gearwheel using a
commercial hook spanner and un-
screw the nut, taking care to retrieve
the safety washer.
•
Remove the water pump gearwheel
Engine SHIVER 900
ENG - 278

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
