APRILIA SHIVER 900 User Manual

Removing the tail pipe
•
Remove the saddle, the rear grab-bar,
the rear light assembly and the number
plate support.
•
Loosen the clamp between the ex-
haust end and the manifold.
•
Remove the two support bracket fas-
tening screws (2) and retrieve the
spacer washers.
•
Slide the exhaust terminal (3) off from
the rear.
•
Remove the exhaust terminal support
bracket fastening screws (4)
Chassis SHIVER 900
CHAS - 350

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
