APRILIA SHIVER 900 User Manual

Front fork
FRONT FORK
Pos. Description Type Quantity Torque Notes
1 Flanged, hex. head screws used for
closing the fork feet
M6x40 4 10 Nm (7.38 lb ft) -
2 Button head, hex. socket screws
used for fastening the sensor to the
right hand fork foot
M5x16 1 6 Nm (4.43 lb ft) -
Adjustment
The front suspension consists of a hydraulic fork
connected to the headstock by means of two
plates.
The right stem of the fork has an upper nut (2) for
adjusting the spring pre-load and an upper adjust-
ment screw (1) for adjusting the hydraulic braking
in rebound.
DO NOT FORCE THE ROTATION OF THE ADJUSTMENT
SCREW BEYOND THE LIMIT STOP IN BOTH DIRECTIONS,
IN ORDER TO PREVENT ANY DAMAGE.
WHEN SPRING PRE-LOAD IS INCREASED, REBOUND
DAMPING MUST ALSO BE INCREASED TO PREVENT EX-
CESSIVE SUSPENSION KICKBACK WHEN RIDING.
Suspensions SHIVER 900
SUSP - 294

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
