Remove the cable clamp fastening
screw positioned inside the fork foot in
order to free the ABS sensor wiring
hardness.
NOTE
THE OPERATIONS DESCRIBED BELOW REFER TO ONE
ROD ONLY, BUT APPLY EQUALLY TO BOTH RODS.
•
Unscrew the screw that fastens the rod
to the upper steering plate.
•
Unscrew the screws that fasten the rod
to the lower steering plate.
•
Slide the rod of the steering plates and
remove it.
Disassembling the fork
NOTE
THE STEMS ARE NOT THE SAME, THEREFORE THEY REQUIRE SEPARATE REMOVAL PRO-
CEDURES.
Suspensions SHIVER 900
SUSP - 296
