APRILIA SHIVER 900 User Manual

Oil pump
LUBRICATION
Pos. Description Type Quantity Torque Notes
1 Oil drainage plug M16x1.5 1 17 Nm (12.54 lb ft) +/-
15%
-
2 Oil pressure sensor M10x1 1 13 Nm (9.59 lb ft) -
3 Fitting fixing of the oil filter - 1 20 Nm (14.75 lb ft) -
SHIVER 900 Engine
ENG - 277

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
