APRILIA SHIVER 900 User Manual

HEAD COVER
Pos. Description Type Quantity Torque Notes
1 Special head cover fastening screw M6 8 9 Nm (6.64 lb ft) -
HEAD
Pos. Description Type Quantity Torque Notes
1 Water Temperature Sensor M12x1.5 1 20 Nm (14.75 lb ft) -
2 Threaded plug M12x1.5 1 10 Nm (7.38 lb ft) Loct. drise AL 506
3 Nut for fastening the stud bolts to the
head - Pre-tightening
M10x1.25 8 13 Nm (9.59 lb ft) Lubricate the
threads before tight-
ening
3 Nut for fastening the stud bolts to the
head - Tightening
M10x1.25 8 135° + 135° -
4 Head / Cylinder / Crankcase fasten-
ing outside
M6x75 2 13 Nm (9.59 lb ft) -
5 Head / Cylinder / Crankcase fasten-
ing inside
M6x125 4 13 Nm (9.59 lb ft) -
6 Nut for fastening the Stud bolts to the
Head
M6 4 12 Nm (8.85 lb ft) -
7 Nut for fastening the Stud bolts to the
Head
M8x1.25 2 25 Nm (18.44 lb ft) -
8 Screw for fastening the connector to
the discharge
M5 4 6 Nm (4.43 lb ft) Loct. dry loc 2040
9 Water vent connector M6 1 3 Nm (2.21 lb ft) Loct. 262
SHIVER 900 Engine
ENG - 235

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
