Measure the thickness of the clutch
discs at four positions, replace them if
not complying with specifications.
Thickness of nine drive discs: 2.5 mm (0.10 in).
Driven disc thickness: 2,75 - 2,85 mm (0.108 ÷
0.112 in).
MUSHROOM VALVE CHECK
•
Check if the valve slides freely, without
jamming.
•
Blow compressed air into the valve and
check that the lubricating oil passage
holes open.
Checking the clutch housing
•
Remove the clutch bell.
•
Remove the seeger ring.
•
Remove the oil pump's drive gear.
DURING REASSEMBLY, THE COLLAR OF THE GEAR
MUST ALWAYS BE FACING THE CLUTCH BELL.
SHIVER 900 Engine
ENG - 229

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
