APRILIA SHIVER 900 User Manual

8. Shoulder washer
9. Shoulder washer
10.Snap ring
11.Floating bushing
12.Secondary transmission shaft
13.1st gear on secondary Z=36
14.2nd gear on secondary Z=32
15.3rd gear on secondary Z=30
16.4th gear on secondary Z=28
17.5th gear on secondary Z=26
18.6th gear on secondary Z=25
19.Floating bushing
20.Shoulder washer
21.Shoulder washer
22.Shoulder washer
23.Shoulder washer
24.Snap ring
25.Shoulder washer
26.Floating bushing
Disassembling the gearbox
•
Remove the gear shift selector as de-
scribed in the Crankcase Opening sec-
tion.
•
Remove the two fork pins.
•
Extract the desmodromic control.
SHIVER 900 Engine
ENG - 209

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
