APRILIA SHIVER 900 User Manual

Inspecting the crankcase halves
BEARINGS AND OIL SEAL CHECK
Thoroughly clean the two sections of the crankcase, the ball bearings, the threads of the crankcase
fixing screws and the bearing seats with a non-aggressive solvent. Clean the seal surfaces and check
that they are not damaged.
CAUTION
TO AVOID DAMAGING BOTH CRANKCASE HALVES PLACE THEM ON A FLAT SURFACE.
Check that both crankcase halves are not cracked or damaged.
Check that all threads are in proper conditions.
Check that all oil seals remaining in their position are not worn or damaged.
Check all ball bearings for clearance, smoothness and potential distortions.
CAUTION
LUBRICATE BALL BEARINGS WITH ENGINE OIL BEFORE FURTHER CHECKING.
If the internal ring does not rotate smoothly and silently or if there is some noise while it turns, it means
that the bearing is faulty and must be replaced.
OIL FILTER AND OIL DELIVERY PIPE CHECK
Check the oil filter for damage. If necessary, replace the part.
Clean the oil net with petrol and inspect the net links for potential damage.
CHECK THE ENGINE OIL FILTER O-RING.
LUBRICATION CHECK
•
Working on both crankcase halves, re-
move and thoroughly clean the nozzle
that lubricates the piston crown.
REPLACE THE SPRAY NOZZLE O-RING IF NECESSARY.
SHIVER 900 Engine
ENG - 271

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
