APRILIA SHIVER 900 User Manual

Wheels
Front wheel
FRONT WHEEL
Pos. Description Type Quantity Torque Notes
1 Wheel axle nut - 1 80 Nm (59.00 lb ft) -
2 Flanged, hex. head phonic wheel
and brake discs fixing screws
M8x20 12 30 Nm (22.13 lb ft) Pre-impregnated
screws
Removal
•
Position the motorcycle on the central
and rear stand so that the front wheel
is slightly raised.
•
Remove the front brake callipers, the
mudguard, the nut and the washer.
Chassis SHIVER 900
CHAS - 320

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
