APRILIA SHIVER 900 User Manual

•
loosened pins;
•
dry, rusty, flattened or jammed chain links;
•
excessive wear;
•
missing sealing rings;
•
excessively worn or damaged pinion or sprocket teeth;
IF THE CHAIN ROLLERS ARE DAMAGED, THE PINS ARE LOOSE AND/OR THE SEAL RINGS
ARE DAMAGED OR MISSING, THE ENTIRE CHAIN UNIT (PINION, SPROCKET AND CHAIN)
NEEDS TO BE REPLACED.
LUBRICATE THE CHAIN REGULARLY, ESPECIALLY IF THERE ARE DRY OR RUSTY PARTS.
CRUSHED OR SEIZED LINKS MUST BE LUBRICATED AND RESTORED TO PROPER WORKING
ORDER.
THE DRIVE CHAIN HAS SEAL RINGS BETWEEN THE LINKS, WHICH KEEP THE GREASE INSIDE.
BE EXTREMELY CAREFUL WHEN ADJUSTING, LUBRICATING, WASHING AND REPLACING
THE CHAIN.
CLEANING AND LUBRICATION
Do not wash the chain with water jets, vapour jets, high-pressure water jets and highly flammable sol-
vents.
•
Wash the chain with naphtha or kerosene. If it tends to rust quickly, carry out the mainte-
nance operations more frequently.
Lubricate the chain at the intervals shown in the routine maintenance table and whenever necessary.
•
After washing and drying the chain, lubricate it with spray grease for sealed chains.
Chassis SHIVER 900
CHAS - 336

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
