Page #433 background imageLoading...
Page #433 background image
•
Disconnect the connector (6) and re-
move the instrument panel (7).
•
Remove the four screws (8) in order to
separate the instrument panel (7) from
the plastic support (9)
Tail guard
REAR BODYWORK
Pos. Description Type Quantity Torque Notes
1 Button head, hex. socket screws
used for fastening the covers to the
terminal
M6x20 6 10 Nm (7.38 lb ft) -
SHIVER 900 Bodywork
BODYW - 433

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the APRILIA SHIVER 900 and is the answer not in the manual?

APRILIA SHIVER 900 Specifications

General IconGeneral
Displacement896.1 cc
Transmission6-speed
Rear Brakes240 mm disc, single-piston caliper
Engine TypeV-Twin, 4-stroke
Power70 kW (95.2 hp) @ 8, 750 rpm
Torque90 Nm at 6, 500 rpm
Fuel SystemElectronic fuel injection
Front SuspensionInverted fork with adjustable preload and rebound damping
Rear SuspensionAluminum swingarm with adjustable rebound and preload
Front BrakesDual 320 mm discs, radial 4-piston calipers
ABSStandard
Traction ControlAdjustable traction control
Ride ModesSport, Touring, Rain
Seat Height810 mm
Wheelbase1, 460 mm
Fuel Capacity15 liters
Dry Weight199 kg (439 lbs)
