Position the thrust plate.
•
Fit the clutch springs.
•
Fit the screw washers.
•
Tighten the six screws operating in
stages and diagonally.
•
Replace the gasket upon refitting.
Head and timing
Engine SHIVER 900
ENG - 234

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the APRILIA SHIVER 900 and is the answer not in the manual?

APRILIA SHIVER 900 Specifications

General IconGeneral
Displacement896.1 cc
Transmission6-speed
Rear Brakes240 mm disc, single-piston caliper
Engine TypeV-Twin, 4-stroke
Power70 kW (95.2 hp) @ 8, 750 rpm
Torque90 Nm at 6, 500 rpm
Fuel SystemElectronic fuel injection
Front SuspensionInverted fork with adjustable preload and rebound damping
Rear SuspensionAluminum swingarm with adjustable rebound and preload
Front BrakesDual 320 mm discs, radial 4-piston calipers
ABSStandard
Traction ControlAdjustable traction control
Ride ModesSport, Touring, Rain
Seat Height810 mm
Wheelbase1, 460 mm
Fuel Capacity15 liters
Dry Weight199 kg (439 lbs)
