Extract the timing chain from the crank-
shaft.
NOTE
IT IS ADVISABLE TO MARK THE CHAIN IN ORDER TO EN-
SURE THAT THE INITIAL DIRECTION OF ROTATION IS
MAINTAINED.
•
Remove the timing chain complete
with the gear.
See also
Removing the
chain sliders
Removing the
chain tensioner
Removing the chain sliders
•
Remove the chain tensioner and the
camshafts for the head in question.
FRONT HEAD
•
In order to remove the front head's
chain sliders, it is necessary to remove
the clutch cover.
•
Unscrew and remove the mobile chain
tensioner slider's screw.
•
Remove it by extracting it from the
head.
Engine SHIVER 900
ENG - 246

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
