APRILIA SHIVER 900 User Manual

FRONT MUDGUARD - ENGINE FAIRING
Pos. Description Type Quantity Torque Notes
1 Button head hex. socket screws
used to fasten the mudguard to the
calliper mounting bracket
M5x9 4 4 Nm (2.95 lb ft) Loct. 243
2 Button head hex. socket screws for
fastening the engine fairing to the
support
M6x20 4 10 Nm (7.38 lb ft) -
•
Working on both sides of the vehicle, undo and remove the four screws that secure the
mudguard.
•
Remove the mudguard
Rear grab rail
•
Unscrew and remove the screws (1)
used for fastening the rear wiring har-
ness protection cover.
Bodywork SHIVER 900
BODYW - 428

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
