APRILIA SHIVER 900 User Manual

•
Taking care not to damage it, secure
the sleeve horizontally in a vice, using
the appropriate protection devices.
•
Extract the dust guard (4).
Specific tooling
AP8140149 Guard for assembly operations
•
Remove the seeger ring (5) from inside
the sleeve.
•
Pull the stem repeatedly towards your-
self in order to remove it from the
sleeve.
•
Observing the indicated sequence, ex-
tract and remove the slider bushing (6),
the guide bushing (7), the ring (8), the
oil seal (9), the seeger ring (5) and the
dust guard (4).
Checking the components
Stem
Check that the sliding surface is not scratched or scored.
Any scoring can be removed by sanding with damp sandpaper (grain 1).
Suspensions SHIVER 900
SUSP - 302

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
