APRILIA SHIVER 900 User Manual

•
Remove the external screw used for
fastening the tail fairing to the side fair-
ing.
•
Remove the two internal screws used
fro fastening tail fairing to the side fair-
ing and separate them.
•
If necessary, in order to remove the ig-
nition switch assembly, disconnect the
saddle opening cable and remove it.
Copertura terminale
•
Remove the saddle, the rear grab-bar,
the rear light assembly and the number
plate support in order to remove the
terminal covers.
The following operations refer to a single cover,
but are valid for both:
•
Remove the lower fastening screw (1)
and retrieve the "T" bushing with the
rubber grommet.
SHIVER 900 Bodywork
BODYW - 435

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
