APRILIA SHIVER 900 User Manual

•
Remove the gasket on the cylinder
base.
See also
Chain removal
Removing the
cylinder head
Disassembling the piston
•
Remove the big end and the cylinder.
•
Extract the pin locking ring.
•
Lock the connecting rod using the spe-
cific tool.
•
Slide the pin and remove the piston.
Specific tooling
020716Y Connecting stem lock
Engine SHIVER 900
ENG - 252

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
