APRILIA SHIVER 900 User Manual

Pedaline
FOOTRESTS
Pos. Description Type Quantity Torque Notes
1 Flanged, hex. head screws used for
fastening the rider/passenger rubber
footrests
M6x12 8 10 Nm (7.38 lb ft) -
2 Cyl. head, hex. socket screws used
for fastening the rider's footrest sup-
port to the frame plates
M8x25 4 18 Nm (13.28 lb ft) Loct. 243
3 Button head, hex. socket screws
used for fastening the luggage rack
to the rider's footrest support
M6x12 4 8 Nm (5.90 lb ft) -
4 Cyl. head, hex. socket screws used
for fastening the passenger footrest
supports to the saddle support
M10x30 4 50 Nm (36.88 lb ft) Loct. 243
Rimozione
LEFT RIDER FOOTREST
•
Remove the two fastening screws (1).
SHIVER 900 Chassis
CHAS - 337

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
