APRILIA SHIVER 900 User Manual

Removing the starter motor
•
In order to remove the starter motor
complete with the support bracket, it is
necessary to remove the two screws
(1).
•
If the bracket needs to be removed
from the starter motor, first remove the
two screws (2) and then the other
screws (1).
Generator side
IGNITION
Pos. Description Type Quantity Torque Notes
1 Spark plug - 2 13 Nm (9.59 lb ft) -
2 Free wheel ring fastening screw M6x18 6 14 Nm (10.33 lb ft) 3M SCOTCH GRIP
2353
3 Rotor fastening screw - Crankshaft M14x1.5 1 191 Nm (140.87 lb ft) Thoroughly de-
grease both of the
coupling surfaces
4 Stator fastening screw / Flywheel
cover
M6x30 3 9 Nm (6.64 lb ft) -
5 Pick-up fastening screw / Flywheel
cover
M5x14 2 3 Nm (2.21 lb ft) Loct. 270
6 Flywheel cover fastening screw M6x30 10 13 Nm (9.59 lb ft) -
7 Crankshaft access plug - 1 4 Nm (2.95 lb ft) -
8 Crown containment plate fastening
screw
M6x12 1 8 Nm (5.90 lb ft) -
SHIVER 900 Engine
ENG - 215

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
