Remove the oil pump stator.
CAUTION
CHECK THAT THE ROTOR AND STATOR ARE NOT DAM-
AGED (NO EVIDENT ABRASIONS, SCORES OR ANY OTH-
ER MARKS).
Installing
NOTE
PAY ATTENTION TO ALIGN THE REFERENCES ON STA-
TOR AND ROTOR DURING INSTALLATION AND CHECK
CLEARANCE WITH A FEELER GAUGE.
IF REQUIRED, REPLACE THE STATOR / ROTOR UNIT.
•
Fit the oil pump in its seat.
SHIVER 900 Engine
ENG - 281

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the APRILIA SHIVER 900 and is the answer not in the manual?

APRILIA SHIVER 900 Specifications

General IconGeneral
Displacement896.1 cc
Transmission6-speed
Rear Brakes240 mm disc, single-piston caliper
Engine TypeV-Twin, 4-stroke
Power70 kW (95.2 hp) @ 8, 750 rpm
Torque90 Nm at 6, 500 rpm
Fuel SystemElectronic fuel injection
Front SuspensionInverted fork with adjustable preload and rebound damping
Rear SuspensionAluminum swingarm with adjustable rebound and preload
Front BrakesDual 320 mm discs, radial 4-piston calipers
ABSStandard
Traction ControlAdjustable traction control
Ride ModesSport, Touring, Rain
Seat Height810 mm
Wheelbase1, 460 mm
Fuel Capacity15 liters
Dry Weight199 kg (439 lbs)
