APRILIA SHIVER 900 User Manual

Installing the chain tensioner
•
Fit the chain tensioner body on the cyl-
inder and insert a new paper gasket.
•
Tighten the two screws to the prescri-
bed torque.
•
Insert the spring and tighten the screw
together with the washer.
Cam timing
Timing
•
Position the plate (1) of the specific
timing tool and lock it in place using the
two screws (2) on the cover.
•
Insert the tool (3) on the crankshaft,
making sure that the pin (4) mounted
on the crankshaft is inserted into the
seat on the tool (5).
Specific tooling
020720Y Timing tool
Engine SHIVER 900
ENG - 248

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
