APRILIA SHIVER 900 User Manual

Pos. Description Type Quantity Torque Notes
3 Pump cover / Clutch cover / clutch
side half-crankcase fastening screw
M6x60 2 13 Nm (9.59 lb ft) -
4 Water pump control crown fastening
nut
M6 1 12 Nm (8.85 lb ft) Loct. 244
5 Water pump impeller (brass insert) M6 1 4 Nm (2.95 lb ft) -
6 Flanged hex head screw for fasten-
ing the chain tensioner slider
M6x12 1 9 Nm (6.64 lb ft) Loct. 242
7 Pump support fastening screw M6x30 3 12 Nm (8.85 lb ft) -
•
Remove the water pump cover.
•
Undo and remove the eleven screws
working in a diagonal sequence.
•
Collect the gasket.
Removing the clutch cover
CLUTCH COVER
Pos. Description Type Quantity Torque Notes
1 Clutch cover / Clutch side cover fas-
tening screw
M6 6 13 Nm (9.59 lb ft) -
2 Clutch fastening nut M24x1.5 1 177 Nm (130.55 lb ft) Chamfer
3 Oil filler cap on clutch cover M25x1.25 1 2 Nm (1.48 lb ft) -
4 Clutch Control Plate / Support coun-
tersunk hex head fastening screw
M5x12 3 5 Nm (3.69 lb ft) 3M SCOTCH GRIP
2353
SHIVER 900 Engine
ENG - 223

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
