Unscrew and remove the fixed chain
tensioner slider's screw.
•
The head must be removed in order to
remove it.
REAR CYLINDER HEAD
•
In order to remove the rear head's
chain sliders, it is necessary to remove
the flywheel.
•
Unscrew and remove the mobile chain
tensioner slider's screw.
•
Remove it by extracting it from the
head.
•
Unscrew and remove the fixed chain
tensioner slider's screw.
•
The head must be removed in order to
remove it.
See also
Removing the
chain tensioner
Removing the
head cover
Magneto flywheel removal
Checking the chain
Check the timing chain for damage or stiffness while moving. If required, replace both the timing chain
and the camshaft sprocket wheels.
Check the timing chain guide for damage. If necessary, replace the parts.
SHIVER 900 Engine
ENG - 247

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
