Remove the gearwheel alignment tool.
Specific tooling
020718Y Camshaft gearwheel alignment pin
•
Reposition the cam tower and the cam-
shafts, applying the pre-defined tight-
ening torque.
•
Rotate the camshaft anticlockwise until
the rear cylinder piston is at TDC (B).
•
Repeat the timing procedure for the
front cylinder.
Specific tooling
020720Y Timing tool
CAUTION
AT TDC THE REAR BIG END CAMS MUST BE DIVERGENT.
Cylinder-piston assembly
Removing the cylinder
•
After having removed the head com-
plete with the timing system, extract
the cylinder from the stud bolts.
SHIVER 900 Engine
ENG - 251

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
