APRILIA SHIVER 900 User Manual

•
Position the gasket on the cylinder
base.
•
Insert the head onto the stud bolts.
•
Apply the nuts (1) to the stud bolts and
tighten them to the required torque val-
ue, proceeding in a crossover fashion.
•
Insert and tighten the internal screws
(2).
•
Insert and tighten the external screws (3, 4, 5).
Installing the head cover
CAUTION
SHIVER 900 Engine
ENG - 261

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
