Pos. Description Type Quantity Torque Notes
9 Bracket to starter motor fastening
screw
M6x14 2 7 Nm (5.16 lb ft) Loct. 242
10 Starter motor bracket to crankcase
fastening screw
M6x16 2 13 Nm (9.59 lb ft) -
Removing the flywheel cover
•
Remove the flywheel cover inspection
cap.
•
Unscrew and remove the ten screws (1
- 2).
NOTE
THE SCREW (2) FOR THE FLYWHEEL COVER IS SHORT-
ER THAN THE OTHER SCREWS (1).
•
Position the appropriate tool in screw it
in a clockwise direction until the fly-
wheel cover has been partially extrac-
ted.
Specific tooling
020712Y Handle for removing the flywheel cov-
er
•
Remove the flywheel cover.
Specific tooling
020712Y Handle for removing the flywheel cov-
er
Engine SHIVER 900
ENG - 216

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
