Removing the flywheel cover components
•
Remove the two pick-up fixing screws.
•
Remove the three stator fixing screws.
CAUTION
THE PICK-UP AND STATOR SHALL BE REMOVED SIMUL-
TANEOUSLY AS THEY ARE PART OF THE SAME ELEC-
TRICAL BRANCH.
Magneto flywheel removal
•
Remove the flywheel cover.
•
Unscrew and remove the screw and
remove the retention plate.
•
Use a heater to heat the flywheel mag-
net.
•
Use the appropriate tool to block the
flywheel and loosen the screw.
Specific tooling
020713Y Flywheel extractor
SHIVER 900 Engine
ENG - 217

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
