APRILIA SHIVER 900 User Manual

Removing the chain tensioner
•
Unscrew and remove the screw, and
retrieve the washer and the internal
spring.
•
Unscrew and remove the two screws.
•
Remove the chain tensioner and re-
trieve the gasket.
Chain removal
•
Remove the chain tensioner.
•
Remove the mobile chain slider and
free the fixed chain slider from the fas-
tener.
•
Heat the pin for the intermediate gear
and loosen it.
•
Hold the intermediate gear still and re-
move the pin.
SHIVER 900 Engine
ENG - 245

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
