APRILIA SHIVER 900 User Manual

•
Retrieve the washers (5), the spacers
(6) and the rubber grommets (7), and
replace them if necessary.
Removing the exhaust manifold
FRONT MANIFOLD
•
Remove the lower fairing and cut the
upper clamp (1) that fastens the front
lambda probe wiring harness to the
ABS pump support frame.
•
Remove the lower clamp (2).
•
Disconnect the front lambda probe
connector (3) and free the wiring har-
ness.
SHIVER 900 Chassis
CHAS - 351

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
