APRILIA SHIVER 900 User Manual

Replacement
Check the engine oil level frequently.
To change:
CAUTION
HOT OIL IS MORE FLUID AND WILL DRAIN OUT MORE
EASILY AND COMPLETELY; IDEAL TEMPERATURE IS
REACHED AFTER THE ENGINE HAS RUN FOR ABOUT
TWENTY MINUTES.
OIL BECOMES VERY HOT WHEN THE ENGINE IS HOT; BE
CAREFUL NOT TO GET BURNED WHEN CARRYING OUT
THE OPERATIONS DESCRIBED BELOW.
•
Using a cloth, carefully clean the area of any dirt deposits around the filling cap (1).
•
Place a container with a capacity of more than 4000 cm³ (244 cu in) under the drainage plug
(2).
•
Unscrew and remove the drainage plug (2).
•
Unscrew and remove the filler plug (1).
•
Drain the oil into the container; allow several minutes for oil to drain out completely.
•
Replace the drainage plug sealing washer (2).
•
Remove any metal scrap attached to the drainage plug (2) magnet.
•
Screw and tighten the drainage plug (2).
•
Replace the oil filter.
•
Restore the correct engine oil level, using the recommended engine oil.
Engine oil filter
•
Move the ABS control unit.
•
Drain the motor oil.
•
Remove the oil filter.
•
Screw a new engine oil filter.
•
Restore the correct engine oil level.
CAUTION
NEVER REUSE AN OLD FILTER.
See also
Replacement
Maintenance SHIVER 900
MAIN - 70

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
