Operation
Air conditioning
Heating, ventilation and cool-
ing
Introduction
Climatronic of 3 zones: heats, v
entilates,
cools and dehumidifies the passenger com-
partment considering it as 3 independent air
conditioning areas (driver, front passenger
and rear seats).
There are several ways to switch on the air
conditioning:
●
Press AUTO on the climabar
››
›
Fig. 127
A
●
OR: Pr
ess in the air conditioning menu
›
››
page 149 or in the air conditioning widg-
et.
●
OR: Press in the air conditioning menu
›››
page 149 or in the air conditioning widg-
et.
●
OR: Change the desired temperature.
The Climatronic operates most effectively
with the windows and the sunroof* closed.
Some functions and menu tabs depend on
the equipment.
Dust and pollen filter
The dust and pollen filter with its activated
charcoal cartridge serves as a barrier against
impurities in the air taken into the vehicle in-
terior.
The dust and pollen filter must be changed
regularly so that air conditioner performance
is not adversely affected.
If the filter loses efficiency prematurely due
to use in areas with very high levels of air pol-
lution, the filter must be changed more fre-
quently than stated in the Service Schedule.
WARNING
Reduced visibility through the windows in-
creases the risk of serious accidents.
●
Always ensure that all windows are free of
ice and snow, and that they are not fogged,
so as to maintain good visibility of every-
thing outside.
●
Only drive when you have good visibility.
●
Always ensure that you use the air condi-
tioner and heated rear window to maintain
good visibility.
●
Never leave the air recirculation on for a
long period of time. If the cooling system is
switched off and air recirculation mode
switched on, the windows can mist over
very quickly, considerably limiting visibility.
●
Switch air recirculation mode off when it
is not required.
WARNING
Stuffy or used air will increase fatigue and
reduce driver concentration possibly re-
sulting in a serious accident.
●
Never leave the fresh air fan turned off or
use the air recirculation for long periods of
time; the air in the vehicle interior will not
be refreshed.
CAUTION
●
To replace the pollen filter, always visit a
service centre.
●
Switch the air conditioner off if you think
it may be broken. This will avoid additional
damage. Have the air conditioner checked
by a specialised workshop.
●
Repairs to the air conditioner require
specialist knowledge and special tools. CU-
PRA recommends going to a specialised
CUPRA Service or SEAT Official Service.
Note
●
When the cooling system is turned off, air
coming from the outside will not be dried.
To prevent fogging of the windows, CUPRA
recommends leaving the cooling system
(compressor) turned on. To do this, press
the function button . The icon should
light up.
●
The maximum heat output required to
defrost windows as quickly as possible is
146
