Safety
Fit a child seat with the ISOFIX / i-Size and Top Tether system
Fig. 27 Rear seat: die cut slots to access the ISO-
FIX / iSize securing rings.
Fig. 28 Front passenger seat: ISOFIX/i-Size secur-
ing rings.
Child seats can be secured quickly, easily
and saf
ely on the r
ear side seats with the
“ISOFIX” and Top Tether system.
Two “ISOFIX” retaining rings are fitted on
each rear side seat. In some vehicles, the
rings are secured to the seat frame and, in
others, they are secured to the rear floor.
The “ISOFIX” rings are located between the
rear seat backrest and the seat cushioning
›››
Fig. 27. The Top Tether rings are located
on the rear part of the backrests of the rear
seats (behind the seat backrest or in the
boot)
›››
page 38 .
To understand the compatibility of the “ISO-
FIX” systems in the vehicle, check the table
below.
36
