Control instruments and warning lamps
Power meter
3 Valid for: hybrid vehicles
Fig. 56
Digital instrument panel: Powermeter
(classic view)
Fig. 57 Digital instrument panel: Powermeter (Cu-
pra view)
The lower left hand side of the rev counter
has t
w
o colour coded areas:
Charge: Energy recovery zone.
Power %: Electric traction zone. Indi-
cates the percentage of power used and
the maximum amount of power cur-
rently available.
The power meter shows the usage level of
the electric drive. The power meter bar
shows the current usage level.
A finer coloured border indicates how much
the propulsion can currently be used. De-
pending on the selected driving program and
the current availability of electrical power,
the boundaries of the different colours can
vary.
The following displays can be seen on the
Power meter:
›››
Fig. 56,
›››
Fig. 57
The vehicle recovers electrical energy.
e-Mode electric driving.
The combustion engine must be run-
ning. With the Boost function, the vehi-
cle drives for a short period of time with
maximum power from both the electric
motor and the combustion engine.
Green
Blue
A
B
C
Battery level indicator
3 Valid for: hybrid vehicles
Fig. 58 Digital instrument panel: battery level indi-
cator.
The small arrow next to the battery symbol
on the fuel g
aug
e indicates which side of the
vehicle the charging cover is on.
Note
●
Never drive with the tank completely
empty. Under certain circumstances, the
energy stored in the high-voltage battery
may not be sufficient to reach the nearest
service station.
●
When the outside temperature is very
low, and therefore the high-voltage battery
is very cold, difficulties may arise in starting
the internal combustion engine and the
range in the electric driving mode may be
reduced.
77
