D-Link DSR-150 User Manual

D-Link DSR-Series User Manual 93
Section 6 - Wireless Settings
Wireless Settings
Access Points
This router has an integrated 802.11n/ac radio that allows you to create an access point for wireless LAN clients.
The security/encryption/authentication options are grouped in a wireless Prole, and each congured prole
will be available for selection in the AP conguration menu. The prole denes various parameters for the AP,
including the security between the wireless client and the AP, and can be shared between multiple APs instances
on the same device when needed.
Up to four unique wireless networks can be created by conguring multiple “virtual” APs . Each such virtual AP
appears as an independent AP (unique SSID) to supported clients in the environment, but is actually running on
the same physical radio integrated with this router.
Note: Proles may be thought of as a grouping of AP parameters that can then be applied to not just one but multiple
AP instances (SSIDs), thus avoiding duplication if the same parameters are to be used on multiple AP instances or SSIDs.
The Wireless Network Setup Wizard is available for users new to wireless networking. By going through a few
conguration pages you can enable a Wi-Fi™ network on your LAN and allow supported 802.11 clients to connect
to the congured Access Point. To run the wizard, refer to “#6 Wireless Network Setup” on page 12.
Path: Wireless > General > Access Points
To add, edit, or delete an access point entry:
1. Click Wireless > General > Access Points.
2. Right-click a current entry and select Edit or Delete. To add a new entry, click Add New Access Point.

D-Link DSR-150 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
PC in (D-Sub)	No
USB ports quantity	0
Ethernet LAN (RJ-45) ports	8
Supported network protocols	IPSec, PPTP, L2TP
Security algorithms	3DES, DES, SSL/TLS
VPN tunnels quantity	21
Filtering description	Keyword
MAC address filtering	-
Safety	cUL, LVD (EN60950-1)
Certification	WEEE
Electromagnetic compatibility	FCC Class B, CE Class B, C-Tick, IC
Mean time between failures (MTBF)	240000 h
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	7.44 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
Input voltage	12 V
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Management platform	HTTP, HTTPS, CLI, SNMP v1/v2c/v3
Connectivity technology	Wired
Compliance industry standards	RoHS

Weight and Dimensions

Depth	118 mm
Width	208 mm
Height	35 mm
Weight	- g
