D-Link DSR-150 User Manual

D-Link DSR-Series User Manual 221
Section 9 - Maintenance
Path: Maintenance > Management > SNMP > SNMP Trap List
To create a new SNMP trap:
1. Click Maintenance > Management > SNMP > SNMP Trap List tab.
SNMP Trap List
2. Right-click an entry and select either Edit or Delete. To add a new trap, click Add SNMP Trap.
3. Complete the elds from the table below and click Save.
Field Description
IP Address Enter the IP Address of the SNMP trap agent.
Port Enter the SNMP trap port to which the trap messages will be sent.
Community
Enter the community string to which the agent belongs. Most agents are congured to listen for
traps in the Public community.
Authentication Type Select the SNMP version used by the trap agent. The choices are v1, v2c, or v3.
Save Click save to activate your settings.

D-Link DSR-150 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
PC in (D-Sub)	No
USB ports quantity	0
Ethernet LAN (RJ-45) ports	8
Supported network protocols	IPSec, PPTP, L2TP
Security algorithms	3DES, DES, SSL/TLS
VPN tunnels quantity	21
Filtering description	Keyword
MAC address filtering	-
Safety	cUL, LVD (EN60950-1)
Certification	WEEE
Electromagnetic compatibility	FCC Class B, CE Class B, C-Tick, IC
Mean time between failures (MTBF)	240000 h
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	7.44 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
Input voltage	12 V
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Management platform	HTTP, HTTPS, CLI, SNMP v1/v2c/v3
Connectivity technology	Wired
Compliance industry standards	RoHS

Weight and Dimensions

Depth	118 mm
Width	208 mm
Height	35 mm
Weight	- g
