D-Link DSR-150 User Manual

D-Link DSR-Series User Manual 192
Section 8 - Security
SMTP ALGs
Path: Security > Firewall > ALGs > SMTP ALGs
Simple Mail Transfer Protocol (SMTP) is a text based protocol used for transferring email between mail servers
over the Internet. Typically the local SMTP server will be located on a DMZ so that mail sent by remote SMTP
servers will traverse the router to reach the local server. Local users will then use email client software to retrieve
their email from the local SMTP server. SMTP is also used when clients are sending email and SMTP ALG can be
used to monitor SMTP trac originating from both clients and servers.
1. Click Security > Firewall > ALGs > SMTP ALGs tab.
2. Toggle Status to ON.
3. Enter the port at which the SMTP packets are inspected.
4. Click Save.

D-Link DSR-150 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
PC in (D-Sub)	No
USB ports quantity	0
Ethernet LAN (RJ-45) ports	8
Supported network protocols	IPSec, PPTP, L2TP
Security algorithms	3DES, DES, SSL/TLS
VPN tunnels quantity	21
Filtering description	Keyword
MAC address filtering	-
Safety	cUL, LVD (EN60950-1)
Certification	WEEE
Electromagnetic compatibility	FCC Class B, CE Class B, C-Tick, IC
Mean time between failures (MTBF)	240000 h
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	7.44 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
Input voltage	12 V
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Management platform	HTTP, HTTPS, CLI, SNMP v1/v2c/v3
Connectivity technology	Wired
Compliance industry standards	RoHS

Weight and Dimensions

Depth	118 mm
Width	208 mm
Height	35 mm
Weight	- g
